How to Slice Thin Flexible Phone Grips and Gaskets in Cura Using TPU

Estimated Reading Time: 6 minutes

  • Understand TPU: Learn about the benefits of using Thermoplastic Polyurethane.
  • Design Considerations: Discover key factors in designing for flexibility.
  • Optimize Your Cura Settings: Find recommended adjustments for effective slicing.
  • Validation and Testing: Validate your printed grips and gaskets.
  • Troubleshooting: Overcome common challenges when printing with TPU.

Table of Contents

Understanding TPU and Its Benefits

Thermoplastic Polyurethane (TPU) is increasingly popular among hobbyists and professionals for its flexibility and durability. Its elastic properties make it an ideal material for items requiring both strength and flexibility, such as phone grips or gaskets that must compress down to provide a snug fit.

Notably, combinations of shore hardness levels give you the flexibility to adjust how soft or hard your grips feel. Higher shore hardness values (e.g., 95A) offer more durability but less flexibility, while lower values (e.g., 75A) provide a softer, more elastic end product.

Designing for Flexibility: Key Considerations

When creating parts like phone grips or gaskets, there are several important factors to be mindful of in your design:

  • Shore Hardness Choice: Selecting the suitable shore hardness for your TPU is critical. For grips, aim for a softer TPU (around 75A to 85A) for comfort, while gasket applications may benefit from a harder TPU (85A to 95A) to ensure a good seal.
  • Layer Height: A lower layer height can provide better detail and smoother finishes, which is beneficial for parts that will be handled frequently. For flexible parts, a layer height of 0.1mm to 0.2mm is typically recommended.
  • Perimeters: Setting a higher number of perimeters can improve strength and durability, particularly for phone grips. We recommend using at least 4-5 perimeters for optimal performance.
  • Infill Options: The infill percentage will depend on the intended use of the product. For phone grips, an infill of 15%-20% is usually sufficient. For gaskets, consider using a higher infill density for better stability and sealing.

Printable Grip STL

To make things easier, you can start by importing a simple phone grip STL file that we have prepared for you. Feel free to adjust the dimensions according to your preferences.

Download your Printable Phone Grip STL here.

Setting Up Your Cura Profile for TPU

To slice thin flexible phone grips and gaskets effectively in Ultimaker Cura, here are some recommended settings adjustments you should make:

Step 1: Basic Settings

  • Material Selection: Confirm you’re using TPU in the material settings.
  • Print Speed: Reduce your print speed to about 20-30 mm/s to ensure better adhesion and prevent stringing.
  • Layer Height: Use a layer height of 0.1mm to 0.2mm for enhanced detail and flexibility.

Step 2: Advanced Settings

  • Enable Z-Hop: If your printer supports Z-Hop, enable this to reduce dragging of the extruder across your print. Check out our guide on how to Enable Z-Hop in Cura.
  • Retraction Settings: Adjust your retraction to minimize stringing. Set the retraction distance to about 2mm and speed to 30-40 mm/s.
  • Support Settings: Use Tree Supports if your design requires it, especially for more complex geometries. Read our insights on Cura Tree vs Normal Supports for more details.

Printing Tips for TPU

  • Build Plate Adhesion: Ensure you’re using the right adhesion method. A heated bed set to around 50°C works well for TPU, but consider using a glue stick or painter’s tape for extra grip.
  • Cooling: Use minimal cooling settings; typically, around 20-30% fan speed can help prevent issues like warping while allowing the material to adhere properly.
  • Test Prints: Start with smaller test prints of your grip design to validate your settings before committing to larger prints. This approach helps in troubleshooting if there are any issues with adhesion or layer separation.

Validation Steps for Grip Performance

Once printed, it’s important to validate that your phone grips and gaskets meet performance expectations. Here are recommended testing methods:

  • Fit Test: Ensure the grip fits your device snugly. This helps assess whether adjustments are necessary in your design.
  • Compression Test: For gaskets, compress the part to evaluate how well it retains its shape after being pushed.
  • Durability Test: Conduct drop tests using the grip to see how well it holds up under different conditions.

Troubleshooting Common Issues

Even experienced users might face challenges while printing with TPU. Here are a few tips to troubleshoot effectively:

  • Stringing: If you encounter stringing, increase retraction settings or reduce printing speed.
  • Layer Separation: Ensure your print speeds aren’t too high and that you’re using the correct infill settings. A higher temperature for the print can also help with layer adhesion.
  • First Layer Issues: If your first layer isn’t sticking, ensure your bed level is correct and that you’re using appropriate bed adhesion methods. Our guide on achieving the Perfect First Layer in Cura can be very helpful here.

Conclusion

By following these tips on how to slice thin flexible phone grips and gaskets in Cura using TPU, you can create durable, functional designs tailored to your specific needs. Not only do these settings improve the quality of your 3D prints, but they also foster creativity and innovation in your projects.

Would you like to learn more about optimizing slicer settings or dive into different materials? Explore our other guides like Cura Flow Rate and Line Width Optimization or Cura Strength Tips to further enhance your 3D printing experience. If you found this article helpful, consider subscribing to our blog for more insightful content or following us on social media!

For more tutorials and guides, visit our main homepage.

Let your creativity run wild and happy printing!
